Overview
Item Number: 400-52374
100% Brand New Aftermarket Part From DB Electrical
Product Specs
| Item Condition | Aftermarket Part |
| Description | Alternator |
| Lester | 11156, 11476 |
| Family | Denso SC (Hairpin) |
| Volt | 12 |
| Amps | 150 |
| Regulator Clock | 9:00 |
| Rotation Direction | Clockwise |
| Mount Hole ID 1 | 11.300mm |
| Mount Hole 1 Type | Unthreaded |
| Mount Hole 2 Type | Unthreaded |
| Mount Hole ID 3 | 10.300mm |
| Mount Hole 3 Type | Unthreaded |
| Mounting Ear Thickness | 2.913" |
| Mounting Ear Thickness | 74mm |
| Mounting Ear 2 Thickness | 1.197" |
| Mounting Ear 2 Thickness | 30.400mm |
| Mounting Ear 3 Thickness | 1.705" |
| Mounting Ear 3 Thickness | 43.300mm |
| Fan Location | Internal |
| Regulator Location | Internal |
| Terminal ID 2 | B+ |
| Terminal 2 Size | M8x1.25 |
| Terminal ID 3 | F |
| Terminal 3 Size | Spade |
| Terminal ID 4 | L |
| Terminal 4 Size | Spade |
| Polarity | Negative |
| Number of Grooves | 6 |
| Groove OD | 2.240" |
| Groove OD | 56.900mm |
| Pulley Type | Solid |
| Pulley Outer Diameter | 2.484" |
| Pulley Outer Diameter | 63.100mm |
Applications List
Select Make & Type
| MAKE | TYPE | MODEL | YEAR | ENGINE |
| Chevrolet | Auto and Light Truck | EQUINOX | 2007 | 207cu in, 3.4L V6 |
| Chevrolet | Auto and Light Truck | EQUINOX | 2008 | 207cu in, 3.4L V6 |
| Chevrolet | Auto and Light Truck | EQUINOX | 2009 | 207cu in, 3.4L V6 |
| Chevrolet | Auto and Light Truck | Equinox | 2007 | 3400cc, 3.4L V6 |
| Chevrolet | Auto and Light Truck | Equinox | 2008 | 3400cc, 3.4L V6 |
| Chevrolet | Auto and Light Truck | Equinox | 2009 | 3400cc, 3.4L V6 |
| Pontiac | Auto and Light Truck | TORRENT | 2007 | 207cu in, 3.4L V6 |
| Pontiac | Auto and Light Truck | TORRENT | 2008 | 207cu in, 3.4L V6 |
| Pontiac | Auto and Light Truck | TORRENT | 2009 | 207cu in, 3.4L V6 |
| Pontiac | Auto and Light Truck | Torrent | 2007 | 3350cc, 3.4L V6 |
| Pontiac | Auto and Light Truck | Torrent | 2008 | 3350cc, 3.4L V6 |
| Pontiac | Auto and Light Truck | Torrent | 2007 | 3400cc, 3.4L V6 |
| Pontiac | Auto and Light Truck | Torrent | 2008 | 3400cc, 3.4L V6 |
| Pontiac | Auto and Light Truck | Torrent | 2009 | 3400cc, 3.4L V6 |
| Saturn | Auto and Light Truck | VUE | 2008 | 213cu in, 3.5L V6 |
| Saturn | Auto and Light Truck | VUE | 2009 | 213cu in, 3.5L V6 |
| Saturn | Auto and Light Truck | Vue | 2008 | 3490cc, 3.5L V6 |
| Saturn | Auto and Light Truck | Vue | 2009 | 3490cc, 3.5L V6 |
| Saturn | Auto and Light Truck | Vue | 2010 | 3490cc, 3.5L V6 |
| Saturn | Auto and Light Truck | Vue | 2008 | 3490cc, 3.5L V6, Gas |
| Saturn | Auto and Light Truck | Vue | 2009 | 3490cc, 3.5L V6, Gas |
| Saturn | Auto and Light Truck | Vue | 2010 | 3490cc, 3.5L V6, Gas |
Replaces These Part Numbers
| AC Delco Tools | 334-2790, 334-2934A |
| Arrowhead | AND0420, AND0524, VND0420 |
| Bosch | AL8630N, AL8630X |
| Delco | 15826299, 25862643, 96673482 |
| Denso | 104210-2160, 104210-5070, 104210-5420, 210-0613, 210-0791 |
| General Motors | 15826299, 25862643, 96673482 |
| J&N Electrical Products | 400-52374, 400-52374R |
| Lester | 11156, 11476 |
